Description
The Green X 21 offers a range of selectable fields of view. The Multi FOV option allows users to select the optimum FOV mode while minimizing exposure to areas that are not in the region of interest
Compare Vatech CBCT Models
Scroll horizontally to compare the Vatech A9 vs. the Vatech Smart Plus vs. the Vatech Green X vs. the Vatech Green X 21
| A9 | Smart Plus | Green X | Green X 21 | |
|---|---|---|---|---|
| Features |
Best for:
Implant planning; capturing both maxillary and mandibular arches in a single scan
|
Best for:
Comprehensive dentition coverage using arch-shaped FOV; metal artifact reduction
|
Best for:
Dedicated endodontic imaging; high-resolution single-tooth diagnosis; complex implant planning
|
Best for:
Multiple specialties including general dentistry, implantology, oral surgery, orthodontics, and endodontics
|
| Technical Specifications | ||||
| CT Field of View (FOV) Size | Ø8 x 8 cm | Ø5 x 5 to 10 x 8.5 cm (Anatomical 12 x 9 cm) | Ø4 x 4 to 18 x 15 cm | Ø4 x 4 to 21 x 19 cm |
| Focal Spot | 0.5 mm (IEC 60336) | 0.5 mm (IEC 60336) | 0.5 mm (IEC 60336) | 0.5 mm (IEC 60336) |
| 3D Voxel Size | 0.2 / 0.3 mm | 0.08 to 0.3 mm | 0.05 to 0.3 mm | 0.05 to 0.3 mm |
| Gray Scale | 14 bit | 14 bit | 14 bit | 16 bit |
| CT Scan Time | 18s | 18s | 2.9s (Ø5 x 5 - 8 x 8) / 9s (Ø12 x 9 - 18 x 15) / 18s (Ø4 x 4) | 7s (Ø5 x 5 - 12 x 9) / 15.2s (Ø18 x 15, 21 x 19) / 18s (Ø4 x 4) |
| Pano Scan Time | 11.9 / 14.1s | 14.1 / 7.0s | 4.0 / 14.1s | 4.0 / 14.1s |
| X-Ray Generator | 60-99 kV, 4-10 mA | 60-99 kVp, 4-16 mA | 60-99 kVp, 4-16 mA | 60-99 kVp, 4-16 mA |
| Imaging Technologies | ||||
| CBCT | ✓ | ✓ | ✓ | ✓ |
| Pano | ✓ | ✓ | ✓ | ✓ |
| Model Scan | ✕ | ✓ | ✓ | ✓ |
| Magic Pan Technology | ✓ | ✕ | ✕ | ✕ |
| Compressed Sensing Technology | ✕ | ✓ | ✓ | ✕ |
| Arch-Shaped FOV | ✕ | ✓ | ✕ | ✕ |
| Multi FOV Selection | ✕ | ✓ | ✓ | ✓ |
|
Clever One Software Compatibility
Integrates panoramic, CBCT, intraoral, facial, and STL scan data within a single viewer using AI technology
|
✓ | ✓ | ✓ | ✓ |
| Additional Features | ||||
| Cephalometric Arm Add-On (Optional) | ✓ | ✓ | ✓ | ✓ |
| Ceph Scan Time (If Included) | 1.9s / 3.9s | 1.9s / 3.9s | 1.9s / 4.9s | 0.9s |
|
AI-Powered Diagnostics (through Clever One Software)
Ex: AI lesion/pathology detection; root canal analysis tools; 3D segmentation; implant and endo simulations; Cloud integration
|
✓ | ✓ | ✓ | ✓ |
Specifications
The selection includes the following FOV sizes for diagnostic needs: 21x19, 18x15, 12x9, 12x5, 8x8, 8x5, 5x5 and 4x4. These options cover the full arch region, sinus and left/right TMJ, and suits most oral surgery cases and multiple implant surgeries.
- ENDO MODE WITH HIGH RESOLUTION
- MULTI FOV SELECTION
- ONE SCAN, THREE IMAGES
- MINIMIZE MOTION ARTIFACTS WITH ONE SHOT TECHNOLOGY
- FACE SCAN
